| Part No. |
Width (mm) |
Suitable Bus Ba Size |
| HSS17 |
17 |
9x3mm, 10x3mm |
| HSS20 |
20 |
9x6mm, 10x6mm, 12x3mm |
| HSS25 |
25 |
12x6mm, 15x3mm |
| HSS30 |
30 |
19x6mm |
| HSS35 |
35 |
20x6mm, 25x3mm |
| HSS41 |
41 |
25x6mm, 25x10mm, 25x20mm |
| HSS48 |
48 |
25x12mm, 30x6mm, 30x10mm |
| HSS55 |
55 |
30x12mm, 38x6mm |
| HSS61 |
61 |
38x9mm, 38x12mm, 40x6mm, 40x10mm |
| HSS73 |
73 |
50x6mm |
| HSS81 |
81 |
50x10mm, 50x12mm |
| HSS85 |
85 |
60x6mm, 60x10mm |
| HSS93 |
93 |
60x12mm, 75x6mm |
| HSS103 |
103 |
75x10mm, 75x12mm |
| HSS110 |
110 |
90x6mm, 90x12mm |
| HSS128 |
128 |
100x6mm, 100x10mm |
| HSS140 |
140 |
100x12mm |
| HSS170 |
170 |
125x6mm, 125x12mm, 150x6mm |
| HSS190 |
190 |
150x6mm, 150x10mm, 150x12mm |
| HSS210 |
210 |
175x6mm, 175x10mm, 175x12mm |
| HSS230 |
230 |
200x12mm |
| Properties |
Values |
| Working Tempreture |
90°C |
| Dielectric Strength |
10 KV/mm |
| Insulation Resistance |
20 X 10 10 Ohms at 500V. DC |
| Tensile Strength |
400 Kg/cm (min) |
| Ultimate Elongation |
100% (min) |
| Chemical Resistance |
Good |
| Chemical Resistance |
Good |
| Fire Resistance |
Self Extinguishing |
| Shrinkable Tempreture |
105°C – 110°C for 4-5 mts. |
| Shrinkage |
30% – 35% |
| Dimensional Variance |
+- 1.5mm (for Size 17mm to 61 mm) |
|
+- 3.0mm (for size 73mm to 230mm) |
Color: Red / Yellow / Blue / Black / Green
Length/Roll: 100 Meters / 50 Meters
Wall Thickness : 100 Microns / 180 Microns
Material : PVC
HSS : Heat Shrink Sleeves
Please mention Color, Wall Thickness & Length per roll
required beside the product part no. in the purchase order.
